Aluminium Alloy ASTM B-209 Angles, Channels & Extrusions, Aluminium Alloy 2014 Angles, Channels & Extrusions, Aluminium Alloy UNS A92014 Angles, Channels & Extrusions Supplier in India
Aluminium Alloy UNS A92014 Angles, Channels & Extrusions Exporter, Aluminium Alloy 2014 Angles, Channels & Extrusions, Aluminium Alloy ASTM-B-209, EN573, and EN485 Angles, Channels & Extrusions
JAGDISH METAL is a leading Suppliers & Manufacturer of Aluminium Alloy 2014 Pipes and Tubes, Aluminium Alloy ASTM B-209M Angles, Channels & Extrusions. We are putting forth an extensive variety of Aluminium Alloy 2014 which is having high quality 4 to 5% Copper combination created in expelled bar and profile frame, in the completely warm treated condition.
Aluminium Alloy 2014 Angles, Channels & Extrusions are medium quality alloy pipes with outstanding erosion protection. Aluminium 2014 Angles, Channels & Extrusions are made by outperforming Aluminium between moves underneath weight, it winds up plainly more slender and longer the moving way.
Specification Of Aluminium Alloy 2014 Angles, Channels & Extrusions:
| Standards |
: |
ASTM B-209, EN573, and EN485 |
| Grade |
: |
Aluminium Alloy 2014 (UNS A92014) |
| Thickness |
: |
0.9mm - 7mm |
| Schedule |
: |
SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Length |
: |
Coating 6.5 meters, Anodizing 6.5 meters, Mill finish 5 meters |
| Finish |
: |
Mill, Customer specific finish |
| Surface |
: |
Anodize, electrophoresis, powder coating, PVDF coating, wood grain painting, matted, etc
|
Chemical Composition Of Aluminium Alloy 2014 Angles, Channels & Extrusions:
| Chemical Element |
% Present |
| Silicon (Si) |
0.50 - 0.90 |
| Iron (Fe) |
0.0 - 0.50 |
| Copper (Cu) |
3.90 - 5.00 |
| Zinc (Zn) |
0.0 - 0.25 |
| Manganese (Mn) |
0.40 - 1.20 |
| Magnesium (Mg) |
0.20 - 0.80 |
| Titanium (Ti) |
0.0 - 0.15 |
| Others (Total) |
0.0 - 0.15 |
| Chromium (Cr) |
0.0 - 0.10 |
| Nickel (Ni) |
0.0 - 0.10 |
| Other (Each) |
0.0 - 0.05 |
| Titanium + Zirconium (Ti+Zr) |
0.0 - 0.20 |
| Aluminium (Al) |
Balance |
Mechanical Properties Of Aluminium Alloy 2014 Angles, Channels & Extrusions:
| Mechanical Property |
Value |
| Tensile Strength |
440 Min MPa |
| Proof Stress |
390 Min MPa |
| Hardness Brinell |
133 HB |
Mechanical Properties Of Aluminium Alloy 2014 Angles, Channels & Extrusions:
| Physical Property |
Value |
| Density |
2.82 g/cm³ |
| Modulus of Elasticity |
71 GPa |
| Electrical Resistivity |
0.045 x10^-6 Ω .m |
| Thermal Conductivity |
138 W/m.K |
| Thermal Expansion |
23 x10^-6 /K |
| Melting Point |
535 °C |
