Aluminium Alloy ASTM B928 Angles, Channels & Extrusions, Aluminium Alloy 5082 Angles, Channels & Extrusions, Aluminium Alloy UNS A95082 Angles, Channels & Extrusions Supplier in India
Aluminium Alloy UNS A95082 Angles, Channels & Extrusions Exporter, Aluminium Alloy 5082 Angles, Channels & Extrusions, Aluminium Alloy ASTM B928 ERW Angles, Channels & Extrusions
JAGDISH METAL are suppliers of Aluminium Alloy 5082 Angles, Channels & Extrusions, Aluminium Alloy 5082 Angles, Channels & Extrusions. Aluminium 5082 is an aluminium magnesium alloy which can be hardened by cold work: it is not heat treatable to higher strength
we offer Aluminium Alloy 5082 Angles, Channels & Extrusions in various sizes, thickness, principles and shapes according to changed prerequisites given by our customers.
Specification Of Aluminium Alloy 5082 Angles, Channels & Extrusions
| Grade |
: |
Aluminium Alloy 5082 (UNS A95082) |
| Thickness |
: |
Minimum : 0.9mm & Maximum : 7mm |
| Length |
: |
Coating 6.5 meters, Anodizing 6.5 meters, Mill finish 5 meters. |
| Finish |
: |
Mill, Customer specific finish |
| Surface |
: |
Anodize, electrophoresis, powder coating, PVDF coating, wood grain painting, matted, etc |
Chemical Composition Of Aluminium Alloy 5082 Angles, Channels & Extrusions:
| Chemical Element |
% Present |
| Aluminium (Al) |
95.2 to 98.3% |
| Chromium (Cr) |
0.25% max |
| Copper (Cu) |
0.1% max |
| Iron (Fe) |
0.5% max |
| Magnesium (Mg) |
0.6 to 1.2% |
| Manganese (Mn) |
0.4% to 1.0% |
| Silicon (Si) |
0.7 to 1.3% |
| Titanium (Ti) |
0.1% max |
| Zinc (Zn) |
0.2% max |
| Residuals |
0.15% max |
Physical Composition Of Aluminium Alloy 5082 Angles, Channels & Extrusions:
| Property |
Value |
| Density |
2700 kg/m3 |
| Melting Point |
555°C |
| Modulus of Elasticity |
70 GPa |
| Electrical Resistivity |
0.038x10-6 Ω.m |
| Thermal Conductivity |
180 W/m.K |
| Thermal Expansion |
24x10-6 /K |
Mechanical Properties Of Aluminium Alloy 5082 Angles, Channels & Extrusions:
| Property |
Value |
| Proof Stress |
85 Max MPa |
| Tensile Strength |
150 Max MPa |
| Hardness Brinell |
40 HB |
