Aluminium Alloy 5754 Welded Pipes & Tubes, Aluminium Alloy UNS A95754 Seamless Pipes & Tubes Supplier in India
Aluminium Alloy UNS A95754 Welded Pipes & Tubes Exporter, Aluminium Alloy 5754 Seamless Pipes & Tubes | Aluminium Alloy ASTM B209 ERW Pipes & Tubes
JAGDISH METAL is a Aluminium Alloy 5754 Pipes & Tubes stockist, conveying to the entire of the world. We are ISO 9001:2008 certify and supplies 5754 Aluminium Pipes & Tubes to globally endorsed quality norms for applications.
5754 Aluminium Pipes & Tubes are available in different shape size and thickness according to the needs of our customer. Owing to highly experienced group of qualified professional and use of latest technology machinery, we at Jagdish Metal have supplied high quality 5754 Aluminium alloy Pipes & Tubes to customers throughout the worldwide.
Specification Of Aluminium Alloy 5754 Pipes & Tubes
| Grade | : | Aluminium Alloy 5754 (UNS A95754) |
| Size | : | 8 (1-1/2" / 1.900") |
| Length | : | Single Random, Double Random & Cut Length. |
| End | : | Plain End, Beveled End, Treaded. |
| Form | : | Round, Square, Rectangular, Hydraulic Etc |
| Outer Diameter | : | 0.020″ – 2″ (.2mm – 150mm) |
| Schedule | : | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | : | Seamless / ERW / Welded / Fabricated / LSAW Pipes |
Chemical Composition Of Aluminium Alloy 5754 Pipes & Tubes:
| Element | % Present |
|---|---|
| Si | 0.4 |
| Fe | 0.4 |
| Mn | 0.5 |
| Mg | 2.6-3.2 |
| Al | Balance |
Mechanical Properties Of Aluminium Alloy 5754 Pipes & Tubes:
| Temper | H22 | H24 | H26 | 0/H111 |
|---|---|---|---|---|
| Proof Stress 0.2% (MPa) | 185 | 215 | 245 | 100 |
| Tensile Strength (MPa) | 245 | 270 | 290 | 215 |
| Shear Strength (MPa) | 150 | 160 | 170 | 140 |
| Elongation A5 (%) | 15 | 14 | 10 | 25 |
| Hardness Vickers (HV) | 75 | 80 | 85 | 55 |
